EPIA-M850-12EL

Thông số

Mã nhà sản xuất

EPIA-M850-12EL

Hãng sản xuất

VIA

Processor

1.2GHz VIA Nano™ E

Chipset

VIA VX900 Media System Processor

System Memory

2 x DDR3 1066/800 DIMM sockets Up to 8GB memory size

VGA

Integrated VIA Chrome9™ HD DX9 3D/2D graphics with VC1, MPEG-2, WMV9 and H.264 decoding acceleration

Expansion Slots

1 x PCIe x4 slot

Onboard LVDS

1 x VIA VT1636 LVDS transmitter

Onboard LAN

1 x VIA VT6130 PCIe Gigabit Ethernet controller

Onboard Audio

VIA VT1708S High Definition Audio Codec

Back Panel I/O

1 x PS2 KB/MS port 1 x VGA port 1 x Serial port 1 x HDMI port 1 x GigaLAN port 4 x USB 2.0 ports 3 x Audio phone jacks: Line-out, Line-in and Mic-in (Vertical type, Smart 5.1 support) 1 x TV connector (S-Video/Component/Composite) for EPIA-M850-16FL only

Onboard I/O Connectors

2 x USB pin headers for 4 USB 2.0 ports 1 x Front-panel audio pin header 1 x S/PDIF out connector 2 x Digital I/O pin headers (8 x GPI + 8 x GPO) 1 x KB/MS pin header 1 x LVDS connector (2-CH 24bit LVDS) - No LVDS for EPIA-M850-16FL SKU 3 x Serial port pin headers for COM ports 1 x LPC pin header 1 x SMBus pin header 1 x Front audio pin header 1 x SPI pin header 1 x ATX power connector 2 x SATA port connectors 2 x Smart Fan connectors for CPU and system fans

BIOS

AMI BIOS SPI 4/8Mbit flash memory

Operating System

Windows 7, Windows XP, Windows Embedded Standard, Windows Embedded CE, Linux

System Monitoring & Management

CPU voltage monitoring, System temperature reading Wake-on LAN, Keyboard Power-on, Timer Power-on, Watch Dog Timer, FAN speed detection, System power management, AC power failure recovery

Operating Temperature

0°C ~ 60°C

Operating Humidity

0% ~ 95% (relative humidity; non-condensing)

Form Factor

Mini-ITX 17 cm x 17 cm (6.7" x 6.7")
